Allagash Cabin Kit

Regular
$109,121

Sale
$104,260

POST & BEAM CABIN

1,012 SQ. FT.

The Allagash Cabin offers comfortable living on your hunting property, next to the lake, or on a mountainside. With one and a half stories, this cabin provides all you could need.

KITS SHIPPED NATIONWIDE

Also Available Fully Built

Fully built available in New England only

Additional Sizes Available

3D Model Get Started

Standard Features

1,012 Sq. Ft. Cabin
Sealed Shop Drawings for Timber Frame with Foundation Plan
Exterior 2D Elevation Drawing Package
30-Minute Step by Step Timber Frame Raising Instructional Video
Great Country Timber Frames Toolbox (see store for items included)
Authentic Mortise & Tenon Post & Beam Construction (11' Bent Spacing)
Eastern White Pine Timber Frame with Finished Planed Surface
Traditional Wood Joinery with Hardwood Oak Pegs (no visible fasteners)
8x8 Posts, 8x12 Tie Beams, 6x10 Loft Joists, 8x12 Rafter Plates, 4x8 Arched Braces
9' First Floor Ceiling Height (11'8" eave height)
1x10 Premium Kiln Dried Shiplap Pine Material for Siding & Trim
10-12 Roof Pitch
6x10 Pine Rafters with Authentic Tongue & Fork Joinery
18' x 22' Second Floor Loft Area with 2'-6" Knee-wall & 7'-6" Collar Tie Height
2x8 Premium Kiln Dried T&G Pine V-Groove Loft Flooring & Roof Decking Material
(1) Heavy Timber Pine Stairway to Second Floor (incl stringers, treads, risers, handrail, newel posts)
All Oak Pegs & Timberlok Fasteners Required to Assemble Timber Frame
Stainless Steel Concealed Knife Plates for Posts
Andersen 400 Series Windows per Plan (GBG)
Andersen A Series Entry Doors Per Plan (GBG)
Code Compliant SIP Insulation Package: Walls 4.5" EPS R18
Code Compliant SIP Insulation Package: Roof 8.25" EPS R33
8' x 22' Timber Frame Front Porch Roof
